Why the focal point of a single-mode laser is so hard to find — and how accurate you need to be

An invisible infrared beam, a focal spot around 50 µm wide, and a beam waist that refuses to become a point. Three constraints, and what each process actually requires.

Why the focal point of a single-mode laser is so hard to find — and how accurate you need to be

Of all the parameters that govern a laser welding process, the position of the beam focal point is the hardest to pin down. The task sounds simple — find the point along the beam axis where the diameter is smallest — but several physical constraints work against you at once.

The beam is not an object

The first difficulty is fundamental: a laser beam is not a physical object. That immediately rules out the simplest measuring tools — rulers, callipers, micrometers. There is nothing to place them against.

Compounding this, the majority of lasers used in industrial applications are infrared lasers with a wavelength of approximately 1,060 nm, which falls outside the visible spectrum. The thing you are trying to measure cannot be seen.

The dimensions involved are tiny

The second difficulty is the size of the beam at the focal point. For the optical setups used in battery manufacturing — including the welding of copper and aluminium — the focal spot diameter falls in the range of 45–60 µm.

The beam never becomes a point

The third constraint comes from the physical nature of the beam itself. Because of the laws of wave optics and the Gaussian profile of the beam, it cannot be focused to an infinitely small point. As it approaches the focal point it forms the shape of a so-called beam waist.

The extent of this region is described by the Rayleigh length — the distance over which the beam’s cross-sectional area doubles. Within that region, changes in diameter are gradual rather than abrupt, which is precisely what makes the minimum so hard to identify.

Put the three factors together — an infrared wavelength invisible to the naked eye, a focal spot diameter of roughly 50 µm, and the beam waist phenomenon — and locating the point of minimum beam diameter becomes extremely difficult.

How accurate does the measurement have to be?

The required measurement accuracy should be matched to the specific process. Two things determine it: the thickness of the materials being joined, and the characteristics of the optical system, which directly determine the beam parameters.

Easily weldable materials. For processes involving materials such as steel, with thicknesses expressed in millimetres, lower beam quality lasers are often used, with focal spot diameters of up to 500–700 µm. In these cases, determining the focal point to within 0.5 to 1 mm may be entirely sufficient.

Difficult or impossible-to-weld materials. Where materials are classified as difficult or impossible to weld, advanced lasers with high power density and focal spot diameters as small as 50 µm are required. These processes typically involve very thin materials, with thicknesses not exceeding 300 µm. For such joints, the expected focal point determination accuracy falls in the range of 50–100 µm.

That is a difference of an order of magnitude — and it is the reason a measurement approach that works perfectly well on millimetre-thick steel can be useless on a battery module.

What this means for battery welding

For laser welding used in the production of electric battery modules — particularly for joining bus bars to cells, where thin and often difficult-to-weld materials such as copper are involved — a method with a precision of at least 100–150 µm should be selected. Correct positioning of the focal point relative to the workpiece is what guarantees repeatable conditions and a stable process.

Methods with precision above 500 µm generally prove insufficiently accurate when welding materials in the 250–300 µm thickness range.

Based on the technical article “RMA Focus Finder — A Reliable Method for Determining the Focal Point of a Single-Mode Laser” by Rajmund Pobereżny, Project Manager, RMA.
